Image sensor
1/2.8-type Exmor CMOS
Signal system - HD
1080p/29.97, 1080p/25, 1080i/59.94 (frame out 1080PsF29.97), 1080i/50 (frame out 1080PsF25), 720p/59.94, 720p/50, 720p/29.97, 720p/25
Lens - Focal length
f=4.7 mm (wide) to 94.0 mm (tele)
F1.6 to F3.5
Min. object distance
10 mm (wide) - 800 mm (tele)
*Default: 290 mm
Horizontal viewing angle
55.4 degres (wide) to 2.9 degrees (tele) (1080 mode)
Focus systems
Auto, One-push AF, Manual, Infinity
Min. illumination
High sensitivity mode: 0.5 lx (F1.6, 50 IRE)
Normal mode: 1.7 lx (F1.6, 50 IRE)
Shutter speed
1 to 1/10,000 s
Gain
Auto/Manual/Max. AE Gain Limit (-3 to 28 dB, 2 dB steps)
White balance
Auto, Indoor, Outdoor, One-push, Manual
Exposure control
Auto, Manual, Priority mode (shutter priority & iris priority), Bright, EV compensation, Slow Shutter AE
S/N ratio
More than 50 dB
Pan/Tilt - Angle - Pan
±170°
Pan/Tilt - Angle - Tilt
+90°/-20°
Pan/Tilt - Max. speed - Pan
100°/sec
Pan/Tilt - Max. speed - Tilt
90°/sec
Video output - HD
DVI-I (Digital (RGB) and Analog component)
Camera control - Interface
RS-232C/RS-422
Camera control - Protocol
VISCA
Power requirements
DC 12 V
Operating temperature
0°C to 40°C (32°F to 104°F)
Storage temperature
-20°C to +60°C (-4°F to +140°F)
Dimensions (W x H x D)
145 x 164 x 164 mm (5 3/4 x 6 1/2 x 6 1/2 inches)
Supplied accessories
AC adaptor
AC power cable
IR remote commander unit
Ceiling bracket
Operating instructions
RS-422 connector plug
