M117VG3817IR Tamron DC Auto Iris CS 1/1.7 CCTV Camera Lens

SPECIFICATIONS
M117VG3817IR
Imager Size 1/1.7
Mount Type CS
Focal Length 3.8  -  17mm
Aperture Range F/1.4  -  close
Angle of View
(Horizontal x Vertical) 1/1.7 Wide 121.2°  x  67.2°
Tele 28.1°  x  16.1°
1/1.8 Wide 114.2°  x  63.5°
Tele 26.6°  x  15.2°
Focusing Range 0.3m  -  ∞
Operation Focus Manual with Lock
Zoom Manual with Lock
Iris DC Auto Iris
Back Focus(in air) 8.66mm(in air)
Wave Length Visible Light  -  Near Infrared
Operating Voltage Open 4V
Close 0.5V
Weight 180g ± 5g
Operating Temperature -20°C  -  +60°C
